一般來說新購買的多槽手動超聲波清洗機在廠家出廠前就已經將超聲波的頻率與功率之間進行了好的匹配了，用戶只需要 調整超聲波發生器上的功率電位器或者是功率調整按鈕即可，根據被清洗的產品來調整超聲波功率就可以了。

Generally speaking, the newly purchased multi slot manual ultrasonic cleaner has well matched the ultrasonic frequency and power before leaving the factory. The user only needs to adjust the power potentiometer or power adjustment button on the ultrasonic generator, and adjust the ultrasonic power according to the product to be cleaned.

如果是超聲波的功率對產品表面沒有任何損傷就可以將功率調整到大，如果功率對產品有一定的損傷那就可以考慮將超聲 波功率調整到60%-80%之間然后觀察清洗后產品的損傷情況；

If the ultrasonic power has no damage to the product surface, the power can be adjusted to high. If the power has certain damage to the product, the ultrasonic power can be adjusted to 60% - 80%, and then observe the damage of the product after cleaning;

不是功率越大，對清洗效果越好，而是正確合理的選擇超聲波功率超聲波清洗器超聲清洗效果不一定與(功率×清洗時間) 成正比，有時用小功率，花費很長時間也沒有清除污垢。

It is not that the higher the power is, the better the cleaning effect will be, but the correct and reasonable selection of ultrasonic power ultrasonic cleaner ultrasonic cleaning effect is not necessarily the same as (power × Cleaning time) is proportional, sometimes with small power, it takes a long time to remove dirt.

而如果功率達到一定數值，有時很快便將污垢去除。若選擇功率太大，空化強度將大大增加，清洗效果是提高了，但這時 使較精密的零件也產生蝕點，得不償失。

If the power reaches a certain value, sometimes the dirt will be removed quickly. If the power is too large, the cavitation strength will be greatly increased, and the cleaning effect will be improved, but at this time, the more precise parts will also have corrosion spots, which is not worth the loss.

使用一定年限的多槽手動超聲波清洗機如果用上述方法不能滿足就可以考慮通過調整超聲波發生器內部的磁芯來進行超聲 波功率與頻率的匹配了，匹配方法：

If the multi slot manual ultrasonic cleaner with a certain service life cannot meet the requirements of the above methods, it can be considered to match the ultrasonic power and frequency by adjusting the magnetic core inside the ultrasonic generator. The matching method is as follows:

將電感固定螺絲松開，取出E型磁芯中間所有墊片，接上負載開機，功率調至大，慢慢提起電感磁芯，觀察電流變化，將磁 芯固定在匹配位置（在不改變磁芯之間高度之外的任何條件，此時電流大點為匹配位置。如果磁芯上提時明顯感覺兩磁芯之間 有很大的吸力則需改變頻率，電流過大也需改變頻率）。

Loosen the fixing screws of the inductance, take out all the gaskets in the middle of the E-type magnetic core, connect the load and start the machine, adjust the power to high, slowly lift the inductance magnetic core, and observe the current change, Fix the magnetic core at the matching position (without changing any condition other than the height between the magnetic cores, the matching position is the point where the current is high. If the magnetic core is obviously lifted, it is necessary to change the frequency if there is a great suction between the two magnetic cores, and if the current is too high, it is also necessary to change the frequency).

然后通過比較超聲效果，聲音來確定一佳頻率，根據客戶要求（允許范圍內）調節電流大小（變壓器檔位可解決），調試 機器后觀察散熱片溫度上升平穩且到一定溫度不再升高為好。

Then determine a good frequency by comparing the ultrasonic effect and sound. Adjust the current according to the customer's requirements (within the allowable range) (the transformer gear can be solved). After debugging the machine, observe that the temperature of the heat sink rises steadily and will not rise again when it reaches a certain temperature.

通過以上的介紹相信大家對于多槽手動超聲波清洗機功率調整到多大才合適這個問題應該了解的差不多了吧，如果還需要 了解更多多槽手動超聲波清洗機的一些問題請關注我們網站hn-qzj.com咨詢更多事項！

Through the above introduction, we believe that you should have a good understanding of the problem of how large the power of the multi tank manual ultrasonic cleaner is to be adjusted. If you still need to know more about some problems of the multi tank manual ultrasonic cleaner, please follow our website hn-qzj.com for more information!
